RESTful rendering pipeline for generating sequence and UML diagrams using Mermaid to embed in Github readmes, Markdown docs and more! Mermrender uses Mermaid.JS and Mermaid CLI under the hood.
Credit: https://mermaidjs.github.io/
Setup in VSCode
Check out this awesome guide for setting up diagram rendering within VSCode: https://quintussential.com/archive/2017/12/10/Diagraming-with-Mermaid/
Motivation
Github doesn’t support rendering Mermaid diagrams in their Markdown editor. Mermaid is a powerful tool that uses a well-defined schema to then interpret diagrams into an SVG. The idea of this tool is to allow embedding images dynamically via a REST endpoint to add UML/Sequence diagrams into your documentation/readmes/markdown files easily, whether the editor supports Mermaid or not.
Demo
Usage
1) Generate the diagram code
sequenceDiagram
participant A as Alice
participant J as John
A->>J: Hello John, how are you?
J->>A: Great!
You can edit and render them live on this website: https://mermaidjs.github.io/mermaid-live-editor/
2) Escape the diagram to encode it
Next, you need to run it through an escaper like the following: https://www.freeformatter.com/java-dotnet-escape.html#ad-output
3) Generate the image link to embed
Send a POST
request to localhost:3000/encode
with a diagram
key in the body with the above escaped diagram:
Example Body:
{
"diagram": "sequenceDiagramrn participant Alicern participant Bobrn Alice->>John: Hello John, how are you?rn loop Healthcheckrn John->>John: Fight against hypochondriarn endrn Note right of John: Rational thoughts <br/>prevail...rn John-->>Alice: Great!rn John->>Bob: How about you?rn Bob-->>John: Jolly good!"
}
This will generate a respose:
{
"embed_link": "http://localhost:3000/diagram/2VxdWVuY2VEaWF"
}
You can embed the following embed_link
by using the following syntax:
Markdown
![alt_caption](http://localhost:3000/diagram/2VxdWVuY2VEaWF)
HTML
<img src="http://localhost:3000/diagram/2VxdWVuY2VEaWF"/>
BBCode (Forums)
[img]http://localhost:3000/diagram/2VxdWVuY2VEaWF[/img]
Additional Options
Add the following optional query parameters to add custom dimensions to your images:
(Not yet implemented)
